16-Inch Parallelogram Jointer with ArmorGlide, Helical Cutterhead, 7-1/2 HP, 3Ph 460V (PJ1696T-4)

Stock Number
PM1-1791283T-4

Now featuring ArmorGlide Technology that is low-friction and rust-resistant, the Powermatic PJ1696T, 16-Inch Jointer offers big capacity and performance in a machine that is loaded with features. A large, center-mounted fence assembly adjusts easily on a rack and pinion system with ram lock. Preset stops on the fence body allow for fast angle set up at 45 degrees in and out, and a positive stop for perfect 90-degree angles. The parallelogram design keeps the table in close proximity to the cutterhead for improved finish, and allows for a fast depth of cut adjustment.

This design also ensures the tables remain perfectly parallel even after years of tough duty. The specially-designed solid steel helical cutterhead consists of six rows of precision-ground staggered inserts. This system makes fast work of knife changing and never needs adjustment. The heavy-duty 7-1/2-HP motor delivers all the power you need for even the biggest jobs.


ArmorGlide Technology gives you a low-friction, industrial-grade coating on the work surface that is rust resistant, requires less maintenance, and gives you more control.
Cast iron fence bevel controls with positive stops at 45 degrees and 90 degrees
Full size rabbeting table supports large workpieces for rabbets up to 3/4" deep
Helical cutterhead with 58 two-sided knife inserts reduces noise, eliminates adjustments, and speeds knife change
Large 16" x 96" precision ground cast iron table surface for maximum support and fine finish
Parallelogram construction maintains close table-to-cutterhead proximity and ensures table parallelism
Rack and pinion adjustable cast iron fence system for smoother fence positioning and sturdy work support
NOTE: The recommended max cutting depth for non-rabbeting cuts is 1/8”. The max cutting depth for rabbeting cuts is 1/2" as the manual has always stated.
More Information
Stock NumberPM1-1791283T-4
Model NumberPJ1696T
Warranty5 Year
Type of CutterheadHelical Head
Cutterhead Diameter (In.)4
Maximum Cutting Depth (In.)1/8"
Cuts Per Minute20,800
Cutterhead Speed (RPM)5200.0000
Cutting Capacity (W x D) (In.)16 x 3/4
Dust Collection Minimum CFM Required (CFM)800
Dust Port Outside Diameter (In.)6
Infeed Table Length (In.)47-1/2
Number of Knives58
Motor Power (HP)7-1/2
Motor Voltage (V.)460
Prewired Voltage (V.)460
Motor Phase3
Max.Rabbeting Capacity (In.)3/4"
Table Height from Floor (In.)37-1/2
Gross Weight1400.0
Net weight1280.0
Prop 65Cancer and Reproductive Harm
